Titanium MIM Materials
Titanium Metal Injection Molding (TiMIM) is a premium solution for parts that require low weight, high strength, and excellent corrosion resistance. At XY-GLOBAL, we provide reliable titanium MIM materials for demanding applications, helping you achieve precise performance, stable quality, and efficient production. With carefully controlled material options and proven processing capability, we support your custom titanium part needs from development to mass production.
- Multiple Titanium MIM Grades Available
- Stable Quality Control and Traceability
- Efficient Production for High-Value Applications
Common Titanium Grade for MIM
At XY-GLOBAL, our titanium grades, including Ti-6Al-4V and CP Titanium, are selected to deliver the right balance of strength, lightweight performance, and corrosion resistance for precision applications.
Ti-6Al-4V
Ti-6Al-4V, also known as Grade 5 or TC4, is the most widely used titanium alloy for MIM parts. It offers an excellent balance of low density, high strength, corrosion resistance, and fatigue performance, making it ideal for aerospace, medical, and high-performance precision applications.
CP Titanium Grades
Commercially pure titanium grades are preferred when corrosion resistance, ductility, and biocompatibility are the top priorities. CP Titanium Grade 1 and Grade 2 are commonly selected for medical, chemical, marine, and aerospace-related parts that require reliable forming and stable performance.
Titanium MIM Materials and Properties
Titanium MIM (Metal Injection Molding) materials are highly valued in modern manufacturing for their excellent strength-to-weight ratio, superior corrosion resistance, and strong biocompatibility. In MIM applications, the most common choices are Ti-6Al-4V (Grade 5) and Commercially Pure (CP) Titanium grades. The best material depends on the balance required between mechanical strength, ductility, and environmental resistance.
| Alloy | Type | Main Composition | Density (g/cm³) | Tensile Strength (MPa) | Yield Strength (MPa) | Hardness | Elongation (%) | Best For |
|---|---|---|---|---|---|---|---|---|
| Ti-6Al-4V (Grade 5) | Alpha-beta titanium alloy | Ti, 6% Al, 4% V | ~4.43 | 850–1100 | 750–1000 | 30–40 HRC | 8–15 | Aerospace fasteners, high-load medical implants, sports equipment |
| CP Ti Grade 2 | Commercially pure titanium | Commercially pure Ti | ~4.51 | 350–550 | 275–450 | 70–90 HRB | 20–30 | Chemical & marine hardware, dental implants, corrosion-resistant housings |
| CP Ti Grade 4 | Commercially pure titanium | Ti (higher O/Fe content) | ~4.51 | 550–750 | 480–650 | 90–110 HRB | 15–25 | High-strength medical instruments, aircraft hydraulic fittings |
Why Choose Titanium for MIM Parts
Titanium is ideal for MIM parts that demand lightweight performance, complex shapes, and reliable behavior in high-end applications.
- Low density: Helps reduce overall part weight while maintaining strong functional performance.
- High strength-to-weight ratio: Suitable for components that need strength without added mass.
- Good toughness: Supports durable parts used in demanding service conditions.
- Excellent corrosion resistance: Well suited for medical, aerospace, and harsh-environment applications.
- Strong biocompatibility: Makes titanium a preferred choice for medical and dental parts.
- Good dimensional stability: Helps maintain accuracy in precision components.
- Premium appearance: Provides a clean, high-end finish for visible or specialty parts.
